| Pixel Pitch | P4-P8mm | P6mm | P8mm | P10mm | P16mm | P20mm |
| LED Standard | SMD2121 | SMD2121 | SMD2121 | SMD2121 | SMD2121 | SMD2121 |
| Pixel Density | 31,250pixel/m² | 27889pixel/m² | 15,625pixel/m² | 10,000pixel/m² | 3,906pixel/m² | 2,500pixel/m² |
| Pixel Composition | 1R1G1B | |||||
| Color Temperature | 5500-9300K | |||||
| Power Consumption | Ave.=240w/m²*H; Max.=800W/m²*H | |||||
| Cabinet Size | 240*1000mm/tailorable | |||||
| Cabinet Weight | 1.5kg/m² | |||||
| Brightness | 2500cd/m² | 3000cd/m² | 3500cd/m² | 3500cd/m² | 3500cd/m² | 2500cd/m² |
| Refresh Rate | 1920HZ-3840HZ | |||||
| Viewing Angle | 140°/140°(H/V) | |||||
| Driving Method | static | |||||
| Gray scale | 16bit | |||||
| IP Rating | IP40 | |||||
| Working Temperature | -20°C+60°C | |||||
| Shelf Life | 2 years | |||||
| Life Span | 100000Hours | |||||
